TC1796

System Units (Vol. 1 of 2)

Reset and Boot Operation

User’s Manual 4-23 V2.0, 2007-07

Reset, V2.0

Figure 4-3 Flow Diagram of Bootstrap Loader ASC0 Boot Modes

MCA05611

Initialization of ASC0

Bootstrap Loader Mode 1

RXD0A pin = 1?

yes

RXD0A pin = 0?

Read System Timer

yes

RXD0A pin = 1?

yes

Read System Timer

Calculate difference

Unlock WDT

Enable ASC0 clock

Lock WDT

Initialize ASC0 port pins

Calculate baud rate

(search for best values for

FDV and BG registers)

Initialize ASC0 registers

Data byte

received?

yes

Store data byte in buffer

Decrement byte counter

Byte

counter = 0?

yes

Write word to SPRAM

Increment data pointer

Byte counter = 4

Decrement word counter

Word

counter = 0?

yes

Execute jump to

address D4000000

Enable receiver

Initialize data pointer

Byte counter = 4

Word counter = 32

Transmit identification D5

Ident. byte

transmitted?

yes

Baud rate

detection

Baud rate

calculation

and ASC0

setup

Data

receive

loop
