TC1796
System Units (Vol. 1 of 2)
System Control Unit
User’s Manual 5-28 V2.0, 2007-07
SCU, V2.0
IGP1 [31:30] rw Interrupt Gating Pattern 1
Bit field IGP1 determines how the pattern detection
influences the output lines GOUT1 and IOUT1.
00
B
The detected pattern is not taken into account.
An activation of IOUT1 is always possible due
to a trigger event.
01
B
The detected pattern is not taken into account.
An activation of IOUT1 is not possible.
10
B
The detected pattern is taken into account. An
activation of IOUT1 is only possible due to a
trigger event while the pattern is detected.
11
B
The detected pattern is taken into account. An
activation of IOUT1 is only possible due to a
trigger event while the pattern is not detected.
0 [12:4],
[28:20]
r Reserved
Read as 0; should be written with 0.
