TC1796
System Units (Vol. 1 of 2)
Program Memory Unit
User’s Manual 7-28 V2.0, 2007-07
PMU, V2.0
Table 7-16 Layout of User Configuration Blocks
UCB Page Address Byte(s) Content
UCB0 UCP0 A000 0000
H
[1:0] Protection configuration bits (content as
defined for PROCON0)
A000 0008
H
[9:8] Copy of bytes [1:0]
A000 0010
H
[19:16] First 32-bit keyword of user 0
A000 0014
H
[23:20] Second 32-bit keyword of user 0
A000 0018
H
[27:24] Copy of first 32-bit keyword of user 0
A000 001C
H
[31:28] Copy of second 32-bit keyword of user 0
– others Must be programmed to 00
H
UCP1 – all This page is reserved for future
purposes; must be programmed to 00
H
UCP2 A000 0200
H
[3:0] 32-bit confirmation code: 8AFE15C3
H
A000 0208
H
[11:8] Copy of 32-bit confirmation code
– others Must be programmed to 00
H
UCP3 – all This page is reserved for future
purposes; must be programmed to 00
H
UCB1 UCP4 A000 0400
H
[1:0] Protection configuration bits (content as
defined for PROCON1)
A000 0408
H
[9:8] Copy of bytes [1:0]
A000 0410
H
[19:16] First 32-bit keyword of user 1
A000 0414
H
[23:20] Second 32-bit keyword of user 1
A000 0418
H
[27:24] Copy of first 32-bit keyword of user 1
A000 041C
H
[31:28] Copy of second 32-bit keyword of user 1
– others Must be programmed to 00
H
UCP5 – all This page is reserved for future
purposes; must be programmed to 00
H
UCP6 A000 0600
H
[3:0] 32-bit confirmation code: 8AFE15C3
H
A000 0608
H
[11:8] Copy of 32-bit confirmation code
– others Must be programmed to 00
H
UCP7 – all This page is reserved for future
purposes; must be programmed to 00
H
