TC1796

System Units (Vol. 1 of 2)

Program Memory Unit

User’s Manual 7-60 V2.0, 2007-07

PMU, V2.0

FLASH_PROCON1

Flash Protection Configuration Register User 1

(1024

) Reset Value: 0000 XXXX

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

1514131211109876543210

0 S12L S11L S10L S9L S8L S7L S6L S5L S4L S3L S2L S1L S0L

r rhrhrhrhrhrhrhrhrhrhrhrhrh

Field Bits Type Description

SnL

(n = 0-12)

nrhSector Locked for Write Protection by User 1

These bits indicate whether sector n is write-

protected by user 1 or not.

No write protection installed for sector n.

Write protection installed for sector n.

0 [31:13] r Reserved

Read as 0.
