TC1796

System Units (Vol. 1 of 2)

Memory Maps

User’s Manual 9-8 V2.0, 2007-07

MemMaps, V2.0

13 D000 0000

D000 DFFF

56 Kbyte DMI Local Data RAM

(LDRAM)

SPBBE SPBBE

D000 E000

D000 FFFF

8 Kbyte DMI Dual-Port RAM

(DPRAM)

D001 0000

D3FF FFFF

≈ 64

Mbyte

Reserved

D400 0000

D400 BFFF

48 Kbyte PMI Scratch-Pad RAM

(SPRAM)

D400 C000

D7FF FFFF

≈ 64

Mbyte

Reserved

D800 0000

DDFF FFFF

96 Mbyte External Peripheral Space compare compare

DE00 0000

DEFF FFFF

16 Mbyte External Emulator Space

DF00 0000

DFFF BFFF

≈ 16

Mbyte

Reserved SPBBE SPBBE

DFFF C000

DFFF DFFF

8 Kbyte Boot ROM (BROM)

DFFF E000

DFFF FFFF

8 Kbyte Test ROM (TROM)

Table 9-2 SPB/RPB Address Map of Segment 0 to 14 (cont’d)

Seg-

ment

Address

Range

Size Description Access Type

Read Write
