TC1796

System Units (Vol. 1 of 2)

Memory Maps

User’s Manual 9-17 V2.0, 2007-07

MemMaps, V2.0

D000 0000

D000 DFFF

56 Kbyte Reserved

(DMI Local Data RAM)

PLMBBET PLMBBET

D000 E000

D000 FFFF

8 Kbyte Reserved

(DMI Dual-Port RAM))

D001 0000

D3FF FFFF

≈ 64

Mbyte

Reserved

D400 0000

D400 BFFF

48 Kbyte Reserved

(PMI Scratch-Pad RAM)

ignore ignore

D400 C000

D7FF FFFF

≈ 64

Mbyte

Reserved PLMBBET PLMBBET

D800 0000

DDFF FFFF

96 Mbyte External Peripheral Space EBU

access

EBU

access

DE00 0000

DEFF FFFF

16 Mbyte External Emulator Space

DF00 0000

DFFF BFFF

≈ 16

Mbyte

Reserved PLMBBET PLMBBET

DFFF C000

DFFF DFFF

8 Kbyte Boot ROM (BROM) access PLMBBET

DFFF E000

DFFF FFFF

8 Kbyte Test ROM (TROM)

E000 0000

E7FF FFFF

128

Mbyte

External Peripheral Space EBU

access

EBU

access

E800 0000

EFFF FFFF

128

Mbyte

Reserved PLMBBET PLMBBET

Table 9-4 PLMB Address Map (cont’d)

Seg-

ment

Address

Range

Size Description Action

Read Write
