Infineon Technologies TC1796 User Manual

TC1796
System Units (Vol. 1 of 2)
General Purpose I/O Ports and Peripheral I/O Lines
User’s Manual 10-6 V2.0, 2007-07
Ports, V2.0
P9 F000 1500
H
F000 15FF
H
–
P10 F000 1600
H
F000 16FF
H
–
Table 10-2 Registers Overview
Register
Short Name
Register Long Name Offset
Address
Description
see
Pn_OUT Port n Output Register 00
H
Page 10-13
Pn_OMR Port n Output Modification Register 04
H
Page 10-14
Pn_IOCR0 Port n Input/Output Control Register 0 10
H
Page 10-7
Pn_IOCR4 Port n Input/Output Control Register 4 14
H
Page 10-8
Pn_IOCR8 Port n Input/Output Control Register 8 18
H
Page 10-8
Pn_IOCR12 Port n Input/Output Control Register 12 1C
H
Page 10-9
Pn_IN Port n Input Register 24
H
Page 10-17
Pn_PDR Port n Pad Driver Mode Register 40
H
Page 10-10
Pn_ESR Port n Emergency Stop Register 50
H
Page 10-16
