TC1796

System Units (Vol. 1 of 2)

General Purpose I/O Ports and Peripheral I/O Lines

User’s Manual 10-56 V2.0, 2007-07

Ports, V2.0

P5.5 I General-purpose input P5_IN.P5 P5_IOCR4.PC5 0XXX

MSC0 input SDI0

O General-purpose output P5_OUT.P5 1X00

Reserved

–1X01

1X10

1X11

P5.6 I General-purpose input P5_IN.P6 P5_IOCR4.PC6 0XXX

O General-purpose output P5_OUT.P6 1X00

MSC1 output EN10 1X01

1X11

MLI0 output TVALID0B 1X10

P5.7 I General-purpose input P5_IN.P7 P5_IOCR4.PC7 0XXX

MSC1 input SDI1

O General-purpose output P5_OUT.P7 1X00

Reserved

–1X01

1X10

1X11

1) The port I/O control values P5_IOCRx.Py that are assigned to this reserved alternate output control selection

should not be used. Otherwise, unpredictable output port line behavior may occur.

Table 10-17 Port 5 Functions (cont’d)

Port

I/O Pin Functionality Associated Reg./

I/O Line

Port I/O Control Select.

Reg./Bit Field Value
