TC1796
System Units (Vol. 1 of 2)
General Purpose I/O Ports and Peripheral I/O Lines
User’s Manual 10-62 V2.0, 2007-07
Ports, V2.0
P6.12 I General-purpose input P6_IN.P12 P6_IOCR12.
PC12
0XXX
B
CAN node 2 rec. input 0
CAN node 1 rec. input 1
RXDCAN2
O General-purpose output P6_OUT.P12 1X00
B
Reserved
1)
–1X01
B
1X10
B
1X11
B
P6.13 I General-purpose input P6_IN.P13 P6_IOCR12.
PC13
0XXX
B
O General-purpose output P6_OUT.P13 1X00
B
CAN node 2 output TXDCAN2 1X01
B
Reserved
1)
–1X10
B
1X11
B
P6.14 I General-purpose input P6_IN.P14 P6_IOCR12.
PC14
0XXX
B
CAN node 3 rec. input 0
CAN node 2 rec. input 1
RXDCAN3
O General-purpose output P6_OUT.P14 1X00
B
Reserved
1)
–1X01
B
1X10
B
1X11
B
P6.15 I General-purpose input P6_IN.P15 P6_IOCR12.
PC15
0XXX
B
O General-purpose output P6_OUT.P15 1X00
B
CAN node 3 output TXDCAN3 1X01
B
Reserved
1)
–1X10
B
1X11
B
1) The port I/O control values P6_IOCRx.Py that are assigned to this reserved alternate output control selection
should not be used. Otherwise, unpredictable output port line behavior may occur.
Table 10-19 Port 6 Functions (cont’d)
