TC1796

System Units (Vol. 1 of 2)

General Purpose I/O Ports and Peripheral I/O Lines

User’s Manual 10-67 V2.0, 2007-07

Ports, V2.0

P7.5 I General-purpose input P7_IN.P5 P7_IOCR4.PC5 0XXX

SCU input REQ7

TTCAN input ECTT2

O General-purpose output P7_OUT.P5 1X00

Reserved

–1X01

1X10

1X11

P7.6 I General-purpose input P7_IN.P6 P7_IOCR4.PC6 0XXX

O General-purpose output P7_OUT.P6 1X00

ADC1 output AD1EMUX0 1X01

Reserved

–1X10

1X11

P7.7 I General-purpose input P7_IN.P7 P7_IOCR4.PC7 0XXX

O General-purpose output P7_OUT.P7 1X00

ADC1 output AD1EMUX1 1X01

Reserved

–1X10

1X11

1) The port I/O control values P7_IOCRx.Py that are assigned to this reserved alternate output control selection

should not be used. Otherwise, unpredictable output port line behavior may occur.

Table 10-21 Port 7 Functions (cont’d)

Port

I/O Pin Functionality Associated Reg./

I/O Line

Port I/O Control Select.

Reg./Bit Field Value
