TC1796

System Units (Vol. 1 of 2)

Peripheral Control Processor (PCP)

User’s Manual 11-43 V2.0, 2007-07

PCP, V2.0

Note: If a conditional instruction’s condition code is false, the operation will be treated as

a “No Operation”. Register values will not be changed and the flags will not be

updated.

Table 11-6 Logical Instructions

Logical

And

AND Register AND register (conditionally)

AND.F Content of FPI Bus address location AND register

(byte, half-word or word)

AND.PI Content of PRAM address location AND register

MCLR.PI Clear specified bits within a PRAM location

Logical Or OR Register OR register (conditionally)

OR.F Content of FPI Bus address location OR register

(byte, half-word or word)

OR.PI Content of PRAM address location OR register

MSET.PI Set specified bits within a PRAM location

Logical

Exclusive-

XOR Register XOR register (conditionally)

XOR.F Content of FPI Bus address location XOR register

(byte, half-word or word)

XOR.PI Content of PRAM address location XOR register

Logical Not NOT Invert register (1’s complement, conditionally)

Shift SHL Shift left register

SHR Shift right register

Rotate RL Rotate left register

RR Rotate right register

Prioritize PRI Calculate position of first set bit (1-bit) in register, from left
