Accessing of Control Registers
The control registers are accessible by any master via the FPI Bus. The control registers
must be configured at initialization and then left unaltered. This is typically done by the
CPU. The only setting that can be dynamically modified is the PCP_CS.EN bit. All other
bits must only be modified when PCP_CS.EN = 0 and PCP_CS.RS = 0.
The PCP control and status registers are accessible only to the CPU when it is operating
in Supervisor mode. PCP control and status registers must be accessed with 32-bit read
and write operations only.
Table 11-11 Registers Overview - PCP Registers
Register
Short Name
Register Long Name Offset
Address
1)
1) The absolute register address is calculated as follows:
Module Base Address (Table 11-10) + Offset Address (shown in this column)
Description
see
PCP_CLC PCP Clock Control Register 0000
H
Page 11-55
PCP_ID PCP Module Identification Register 0008
H
Page 11-54
PCP_CS PCP Control/Status Register 0010
H
Page 11-56
PCP_ES PCP Error/Debug Status Register 0014
H
Page 11-59
PCP_ICR PCP Interrupt Control Register 0020
H
Page 11-61
PCP_ITR PCP Interrupt Threshold Control Register 0024
H
Page 11-63
PCP_ICON PCP Interrupt Configuration Register 0028
H
Page 11-64
PCP_SSR PCP Stall Status Register 002C
H
Page 11-66
PCP_SRC11 PCP Service Request Control Register 11 00D0
H
Page 11-70
PCP_SRC10 PCP Service Request Control Register 10 00D4
H
PCP_SRC9 PCP Service Request Control Register 9 00D8
H
PCP_SRC8 PCP Service Request Control Register 8 00DC
H
Page 11-69
PCP_SRC7 PCP Service Request Control Register 7 00E0
H
PCP_SRC6 PCP Service Request Control Register 6 00E4
H
PCP_SRC5 PCP Service Request Control Register 5 00E8
H
PCP_SRC4 PCP Service Request Control Register 4 00EC
H
PCP_SRC3 PCP Service Request Control Register 3 00F0
H
Page 11-68
PCP_SRC2 PCP Service Request Control Register 2 00F4
H
PCP_SRC1 PCP Service Request Control Register 1 00F8
H
Page 11-67
PCP_SRC0 PCP Service Request Control Register 0 00FC
H
