TC1796

System Units (Vol. 1 of 2)

Direct Memory Access Controller

User’s Manual 12-38 V2.0, 2007-07

DMA, V2.0

Figure 12-26 Pattern Detection for 16-bit Data Width (CHCRmn.CHDW = 01

)

MCA05703

PATm3 PATm2 PATm1 PATm0

PATSEL

CHCRmn

Pattern

Detected

LXO

CHSRmn

MEmPR

COMP

RDm3 RDm2 RDm1 RDm0

1516

MEmR

COMP

1) This signal is clocked into LXO after each read move.

INCS

ADRCRmn

1516 7824

782324

Mask

≥1
