TC1796

System Units (Vol. 1 of 2)

LMB External Bus Unit

User’s Manual 13-24 V2.0, 2007-07

EBU, V2.0

CONF32BIT 15 32-Bit Configuration Word

The memory connected to CS0 is 16-bit wide. Bit field

RES32 (bits [31:16]) of the configuration word are

discarded.

The memory connected to CS0 is 32-bit wide. Bit field

RES32 (bits [31:16]) of the configuration word are

potentially available for use as configuration

information.

Note: In the TC1796, the EBU does not actually use bits 31

to 16 of the configuration word when CONF32BIT is 1.

However, to allow future expansion this bit should be

programmed to 0.

RES32 [31:16] Reserved

This bit field is reserved for future use. In the TC1796, RES32

should always be set to 0000

Field Bits Description
