TC1796

System Units (Vol. 1 of 2)

LMB External Bus Unit

User’s Manual 13-64 V2.0, 2007-07

EBU, V2.0

Figure 13-23 Example of a Motorola-style Demultiplexed Device Access

LMBCLK

A[23:0]

Address

MCT05734

AP1

Next. A.

CSx

M/RW

Data in

D[31:0]

AP2 CPi1 CPi2 CPe3 CPe4 CPe5 RP1 RP2

New

AP1

Sample

Read Access

LMBCLK

A[23:0]

Address

AP1

Next. A.

CSx

MR/W

Data out

D[31:0]

AP2 CPi1 CPi2 CPe3 CPe4 RP1 RP2 RP3

New

AP1

Write Access

WAIT

(used as DTACK)

(used as AS)

WAIT

(used as DTACK)

1) At Motorola devices, CS is connected with AS while WAIT (with inverse polarity)

is connected to the DTACK output.
