Table 13-19 Burst Flash Access Programmable Parameters
Register Parameter
(Bit/Bit field)
Function
EBU_BUSAPx
EBU_EMUBAP
ADDRC Number of cycles in address phase; can be
multiplied by CMULT.
CMDDELAY Number of programmed command delay cycles;
can be multiplied by CMULT.
WAITRDC Number of programmed wait states for read
accesses; always multiplied by CMULT.
BURSTC Number of data cycles; can be multiplied by
CMULT.
RDRECOVC Number of minimum recovery cycles after a read
access; can be multiplied by CMULT.
DTACS Number of minimum recovery cycles when the next
access points to a different memory region; always
multiplied by CMULT.
EBU_BUSCONx
EBU_EMUBC
WAIT External Wait State control (OFF, asynchronous,
synchronous)
CMULT Common (cycle) multiplier control (×1, ×4, ×8, ×16,
×32)
MULTMAP Multiplier map, each bit enables multiplier function of
bits and bit fields ADDRC, CMDDELAY, BURSTC
(see next chapter), DATAC, RDRECOVC, and
WRRECOVC.
