TC1796
System Units (Vol. 1 of 2)
Interrupt System
User’s Manual 14-24 V2.0, 2007-07
Interrupt, V2.0
ASC1 4 ASC1 Transmit Interrupt Service Request
Node
ASC1_TSRC
ASC1 Receive Interrupt Service Request Node ASC1_RSRC
ASC1 Error Interrupt Service Request Node ASC1_ESRC
ASC1 Transmit Buffer Interrupt Service
Request Node
ASC1_TBSRC
SSC0 3 SSC0 Transmit Interrupt Service Request
Node
SSC0_TSRC
1)
SSC0 Receive Interrupt Service Request Node SSC0_RSRC
1)
SSC0 Error Interrupt Service Request Node SSC0_ESRC
1)
SSC1 3 SSC1 Transmit Interrupt Service Request
Node
SSC1_TSRC
1)
SSC1 Receive Interrupt Service Request Node SSC1_RSRC
1)
SSC1 Error Interrupt Service Request Node SSC1_ESRC
1)
MSC0 2 MSC0 Service Request Nodes [1:0] MSC0_SRC[1:0]
MSC1 2 MSC1 Service Request Nodes [1:0] MSC1_SRC[1:0]
CAN 16 CAN Service Request Nodes [15:0] CAN_SRC[15:0]
1)
GPTA 38 GPTA0 Service Request Nodes [37:00] GPTA0_SRC
[37:00]
38 GPTA1 Service Request Nodes [37:00] GPTA1_SRC
[37:00]
16 LTCA2 Service Request Nodes [15:00] LTCA2_SRC
[15:00]
ADC0 4 ADC0 Service Request Nodes [3:0] ADC0_SRC[3:0]
1)
ADC1 4 ADC1 Service Request Nodes [3:0] ADC1_SRC[3:0]
1)
FADC 4 FADC Service Request Nodes [3:0] FADC_SRC[3:0]
1)
181 = Total Number of Request Nodes
1) These service request registers are not bit-addressable because its register address is outside the first
16 Kbyte of a segment.
Table 14-2 Service Request Nodes in the TC1796 (cont’d)
Module No. of
Nodes
Description SRC Register
