TC1796
System Units (Vol. 1 of 2)
On-Chip Debug Support
User’s Manual 17-17 V2.0, 2007-07
OCDS, V2.0
CBS_OSTATE Cerberus OSCU Status Register F000 0480
H
CLIENT_ID Cerberus JTAG Client Identification Register (32-bit)
1)
IOCONF Configuration Register (12-bit)
1)
IOINFO State Information for Error Analysis Register (16-bit)
1)
IOADDR Address for Data Access Register (32-bit)
1)
IODATA RW Mode Data Register (32-bit)
1)
TRADDR External Bus Trace Mode Address Register (8-bit)
1)
CBS_JDPID Cerberus Module Identification Register F000 0408
H
CBS_COMDATA Cerberus Communication Mode Data Register F000 0468
H
CBS_IOSR Cerberus Status Register F000 046C
H
CBS_INTMOD Cerberus Internal Mode Status and Control Register F000 0484
H
CBS_ICTSA Cerberus Internal Controlled Trace Source Address
Register
F000 0488
H
CBS_ICTTA Cerberus Internal Controlled Trace Target Address
Register
F000 048C
H
CBS_MCDBBS Cerberus Break Bus Switch Configuration Register F000 0470
H
CBS_MCDBBSS Cerberus Break Bus Switch Status Register F000 0490
H
CBS_MCDSSG Cerberus Suspend Signal Generation Status and
Control Register
F000 0474
H
CBS_MCDSSGC Cerberus Suspend Signal Generation Configuration
Register
F000 0494
H
CBS_SRC Cerberus Service Request Control Register F000 04FC
H
1) These register are only accessible via the JTAG interface.
Table 17-3 JTAG/Cerberus Register Overview (cont’d)
Register
Short Name
Register Long Name Address
To Next Page
