MEASurement<m>:AMPTime:CLCK<n>:LSELect <ClkLevSel>
Selects the reference level of the clock on which the time is measured. Reference level
and clock slope define the time point for setup and hold measurements.
Suffix:
<m>
.
1..10
See "Selection of the measurement: MEASurement<m>"
on page 1249.
<n> 1..2
The suffix is irrelevant, omit it.
Parameters:
<ClkLevSel> UPPer | MIDDle | LOWer
*RST: MIDDle
Usage: Asynchronous command
MEASurement<m>:AMPTime:DATA<n>:LSELect <DatLevSel>
Selects the reference level of the data on which the setup and hold time are measured.
Suffix:
<m>
.
1..10
See "Selection of the measurement: MEASurement<m>"
on page 1249.
<n> 1..2
The suffix is irrelevant, omit it.
Parameters:
<DatLevSel> UPPer | MIDDle | LOWer
*RST: MIDDle
Usage: Asynchronous command
MEASurement<m>:AMPTime:DTOTrigger<n>:SLOPe <DlyTrigSlp>
Sets the edge direction to be used for delay measurement.
Suffix:
<m>
.
1..10
See "Selection of the measurement: MEASurement<m>"
on page 1249.
<n> 1..2
The suffix is irrelevant.
Parameters:
<DlyTrigSlp> POSitive | NEGative | EITHer
*RST: POSitive
Usage: Asynchronous command
