Remote control commands
R&S
®
RTE
1627User Manual 1326.1032.02 ─ 20
SEARch:TRIGger:MILStd:CMD:SMAX <SearchName>,<SubaddrPattMax>
SEARch:TRIGger:MILStd:CMD:SMAX? <SearchName>
SEARch:TRIGger:MILStd:DATA:DMAX <SearchName>,<DataPatternMax>
SEARch:TRIGger:MILStd:DATA:DMAX? <SearchName>
Sets the end value of a pattern range for the corresponding search:
●
CDST:IMAX - specific info for the 9th to 19th bit of a command or status word.
●
CMD:CMAX - specific data word count or mode code pattern in a command word
●
CMD:SMAX - specific subaddress/mode pattern in a command word
●
DATA:DMAX - data pattern in a data word
Parameters:
<DataPatternMax>
Parameters for setting and query:
<SearchName>
SEARch:TRIGger:MILStd:DATA:ICONdition <SearchName>,<DataIdxOperator>
SEARch:TRIGger:MILStd:DATA:ICONdition? <SearchName>
Sets the operator to set a range within a series of the data words that is considered for
the search.
Parameters:
<DataIdxOperator> EQUal | LTHan | LETHan | GTHan | GETHan | INRange |
RANGe
INRange = RANGe
*RST: INRange
Parameters for setting and query:
<SearchName>
SEARch:TRIGger:MILStd:DATA:IMIN <SearchName>,<DataIndexMin>
SEARch:TRIGger:MILStd:DATA:IMIN? <SearchName>
Specifies an index or sets the the start value of a data word series index range.
Parameters:
<DataIndexMin> Range: 1 to 32
Increment: 1
*RST: 1
Parameters for setting and query:
<SearchName>
SEARch:TRIGger:MILStd:DATA:IMAX <SearchName>,<DataIndexMax>
SEARch:TRIGger:MILStd:DATA:IMAX? <SearchName>
Sets the end value of a data word series index range if the operator is set to INRange.
Protocols
