BUS<m>:ETHernet:VARiant..........................................................................................1649
BUS<m>:ETHernet:SOURce.........................................................................................1649
BUS<m>:ETHernet:POLarity.........................................................................................1649
BUS<m>:ETHernet:THReshold:HIGH............................................................................ 1650
BUS<m>:ETHernet:THReshold:LOW.............................................................................1650
BUS<m>:ETHernet:PRESet..........................................................................................1650
BUS<m>:ETHernet:BITRate..........................................................................................1651
BUS<m>:ETHernet:VARiant <Variant>
Selects the Ethernet protocol variant and transmission speed.
Suffix:
<m>
.
1..4
Parameters:
<Variant> B10T | B100TX | B100tx
B10T
Ethernet protocol variant 10BASE-T (10 Mbit/s)
B100TX = B100tx
Ethernet protocol variant 100BASE-TX (100 Mbit/s)
*RST: B10T
BUS<m>:ETHernet:SOURce <SourceData>
Selects the source channel for the data signal.
Usually, the source is one of the analog channels. Reference and math waveforms are
available as source if the trigger source is one of the analog channels but not the serial
bus.
Alternatively, digital channels can be used if MSO option R&S RTE-B1 is installed. Dig-
ital and analog channels cannot be used at the same time.
For triggering on a serial bus, analog or digital channel sources are required.
Suffix:
<m>
.
1..4
Parameters:
<SourceData> C1W1 | C2W1 | C3W1 | C4W1 | M1 | M2 | M3 | M4 | M5 | M6 |
M7 | M8 | R1 | R2 | R3 | R4
See Chapter 18.4.2, "Waveform parameter", on page 1074
*RST: C1W1
BUS<m>:ETHernet:POLarity <Polarity>
Defines the polarity of the data signal. This setting is only available in 10BASE-T.
Protocols
