TC1796
System Units (Vol. 1 of 2)
Register Overview
User’s Manual 18-13 V2.0, 2007-07
Regs, V2.0
Table 18-5 Address Map of STM
Short Name Description Address Access Mode Reset Value
Read Write
System Timer (STM)
STM_CLC STM Clock Control
Register
F000 0200
H
U, SV SV, E 0000 0200
H
– Reserved F000 0204
H
BE BE –
STM_ID STM Module Identification
Register
F000 0208
H
U, SV BE 0000 C0XX
H
– Reserved F000 020C
H
BE BE –
STM_TIM0 STM Timer Register 0 F000 0210
H
U, SV nBE 0000 0000
H
STM_TIM1 STM Timer Register 1 F000 0214
H
U, SV nBE 0000 0000
H
STM_TIM2 STM Timer Register 2 F000 0218
H
U, SV nBE 0000 0000
H
STM_TIM3 STM Timer Register 3 F000 021C
H
U, SV nBE 0000 0000
H
STM_TIM4 STM Timer Register 4 F000 0220
H
U, SV nBE 0000 0000
H
STM_TIM5 STM Timer Register 5 F000 0224
H
U, SV nBE 0000 0000
H
STM_TIM6 STM Timer Register 6 F000 0228
H
U, SV nBE 0000 0000
H
STM_CAP STM Timer Capture Reg. F000 022C
H
U, SV nBE 0000 0000
H
STM_CMP0 STM Compare Register 0 F000 0230
H
U, SV U, SV 0000 0000
H
STM_CMP1 STM Compare Register 1 F000 0234
H
U, SV U, SV 0000 0000
H
STM_
CMCON
STM Compare Match
Control Register
F000 0238
H
U, SV U, SV 0000 0000
H
STM_ICR STM Interrupt Control
Register
F000 023C
H
U, SV U, SV 0000 0000
H
STM_ISRR STM Interrupt Set/Reset
Register
F000 0240
H
U, SV U, SV 0000 0000
H
– Reserved F000 0244
H
-
F000 02F4
H
BE BE –
STM_SRC1 STM Service Request
Control Register 1
F000 02F8
H
U, SV U, SV 0000 0000
H
STM_SRC0 STM Service Request
Control Register 0
F000 02FC
H
U, SV U, SV 0000 0000
H
