Table 18-6 Address Map of Cerberus

Short Name Description Address Access Mode Reset Value

Read Write

On-Chip Debug Support (Cerberus)

– Reserved F000 0400

F000 0404

BE BE –

CBS_JDPID Cerberus Module

Identification Register

F000 0408

U, SV BE 0000 63XX

– Reserved F000 040C

F000 0464

BE BE –

CBS_

COMDATA

Cerberus Communication

Mode Data Register

F000 0468

U, SV SV 0000 0000

CBS_IOSR Cerberus Status Register F000 046C

U, SV SV 0000 0000

CBS_

MCDBBS

Cerberus Break Bus

Switch Configuration

F000 0470

U, SV SV 0000 0000

CBS_

MCDSSG

Cerberus Suspend Signal

Generation Status and

Control Register

F000 0474

U, SV SV 0000 0000

CBS_OEC Cerberus OCDS Enable

Control Register

F000 0478

U, SV SV 0000 0000

CBS_

OCNTRL

Cerberus OSCU

Configuration and Control

F000 047C

U, SV SV 0000 0000

CBS_

OSTATE

Cerberus OSCU Status

F000 0480

U, SV SV 0000 0000

CBS_

INTMOD

Cerberus Internal Mode

Status and Control

F000 0484

U, SV SV 0000 0000

CBS_ICTSA Cerberus Internal

Controlled Trace Source

Address Register

F000 0488

U, SV SV 0000 0000

CBS_ICTTA Cerberus Internal

Controlled Trace Target

Address Register

F000 048C

U, SV SV 0000 0000

CBS_

MCDBBSS

Cerberus Break Bus

Switch Status Register

F000 0490

U, SV SV 0000 0000
