TC1796

System Units (Vol. 1 of 2)

User’s Manual 18-16 V2.0, 2007-07

Regs, V2.0

Table 18-7 Address Map of MSC0/MSC1

Short Name Description Address Access Mode Reset Value

Read Write

Micro Second Channel 0 (MSC0)

MSC0_CLC MSC0 Clock Control

F000 0800

U, SV SV, E 0000 0003

– Reserved F000 0804

BE BE –

MSC0_ID MSC0 Module

Identification Register

F000 0808

U, SV nBE 0028 C0XX

MSC0_FDR MSC0 Fractional Divider

F000 080C

U, SV SV, E 0000 0000

MSC0_USR MSC0 Upstream Status

F000 0810

U, SV U, SV 0000 0000

MSC0_DSC MSC0 Downstream

Control Register

F000 0814

U, SV U, SV 0000 0000

MSC0_DSS MSC0 Downstream

Status Register

F000 0818

U, SV U, SV 0000 0000

MSC0_DD MSC0 Downstream Data

F000 081C

U, SV U, SV 0000 0000

MSC0_DC MSC0 Downstream

Command Register

F000 0820

U, SV U, SV 0000 0000

MSC0_

DSDSL

MSC0 Downstream

Select Data Source Low

F000 0824

U, SV U, SV 0000 0000

MSC0_

DSDSH

MSC0 Downstream

Select Data Source High

F000 0828

U, SV U, SV 0000 0000

MSC0_ESR MSC0 Emergency Stop

F000 082C

U, SV U, SV 0000 0000

MSC0_UD0 MSC0 Upstream Data

F000 0830

U, SV U, SV 0000 0000

MSC0_UD1 MSC0 Upstream Data

F000 0834

U, SV U, SV 0000 0000

MSC0_UD2 MSC0 Upstream Data

F000 0838

U, SV U, SV 0000 0000
