TC1796
System Units (Vol. 1 of 2)
Register Overview
User’s Manual 18-17 V2.0, 2007-07
Regs, V2.0
MSC0_UD3 MSC0 Upstream Data
Register 3
F000 083C
H
U, SV U, SV 0000 0000
H
MSC0_ICR MSC0 Interrupt Control
Register
F000 0840
H
U, SV U, SV 0000 0000
H
MSC0_ISR MSC0 Interrupt Status
Register
F000 0844
H
U, SV U, SV 0000 0000
H
MSC0_ISC MSC0 Interrupt Set Clear
Register
F000 0848
H
U, SV U, SV 0000 0000
H
MSC0_OCR MSC0 Output Control
Register
F000 084C
H
U, SV U, SV 0000 0000
H
– Reserved F000 0850
H
-
F000 0854
H
nBE nBE –
– Reserved F000 0858
H
-
F000 08F4
H
BE BE –
MSC0_
SRC1
MSC0 Service Request
Control Register 1
F000 08F8
H
U, SV U, SV 0000 0000
H
MSC0_
SRC0
MSC0 Service Request
Control Register 0
F000 08FC
H
U, SV U, SV 0000 0000
H
Micro Second Channel 1 (MSC1)
MSC1_CLC MSC1 Clock Control
Register
F000 0900
H
U, SV SV, E 0000 0003
H
– Reserved F000 0904
H
BE BE –
MSC1_ID MSC1 Module
Identification Register
F000 0908
H
U, SV nBE 0028 C0XX
H
MSC1_FDR MSC1 Fractional Divider
Register
F000 090C
H
U, SV SV, E 0000 0000
H
MSC1_USR MSC1 Upstream Status
Register
F000 0910
H
U, SV U, SV 0000 0000
H
MSC1_DSC MSC1 Downstream
Control Register
F000 0914
H
U, SV U, SV 0000 0000
H
MSC1_DSS MSC1 Downstream
Status Register
F000 0918
H
U, SV U, SV 0000 0000
H
Table 18-7 Address Map of MSC0/MSC1 (cont’d)
Short Name Description Address Access Mode Reset Value
Read Write
To Next Page
