TC1796

System Units (Vol. 1 of 2)

User’s Manual 18-18 V2.0, 2007-07

Regs, V2.0

MSC1_DD MSC1 Downstream Data

F000 091C

U, SV U, SV 0000 0000

MSC1_DC MSC1 Downstream

Command Register

F000 0920

U, SV U, SV 0000 0000

MSC1_

DSDSL

MSC1 Downstream

Select Data Source Low

F000 0924

U, SV U, SV 0000 0000

MSC1_

DSDSH

MSC1 Downstream

Select Data Source High

F000 0928

U, SV U, SV 0000 0000

MSC1_ESR MSC1 Emergency Stop

F000 092C

U, SV U, SV 0000 0000

MSC1_UD0 MSC1 Upstream Data

F000 0930

U, SV U, SV 0000 0000

MSC1_UD1 MSC1 Upstream Data

F000 0934

U, SV U, SV 0000 0000

MSC1_UD2 MSC1 Upstream Data

F000 0938

U, SV U, SV 0000 0000

MSC1_UD3 MSC1 Upstream Data

F000 093C

U, SV U, SV 0000 0000

MSC1_ICR MSC1 Interrupt Control

F000 0940

U, SV U, SV 0000 0000

MSC1_ISR MSC1 Interrupt Status

F000 0944

U, SV U, SV 0000 0000

MSC1_ISC MSC1 Interrupt Set Clear

F000 0948

U, SV U, SV 0000 0000

MSC1_OCR MSC1 Output Control

F000 094C

U, SV U, SV 0000 0000

– Reserved F000 0950

F000 0954

nBE nBE –

– Reserved F000 0958

F000 09F4

BE BE –

Table 18-7 Address Map of MSC0/MSC1 (cont’d)

Short Name Description Address Access Mode Reset Value

Read Write
