Infineon Technologies TC1796 User Manual

TC1796
System Units (Vol. 1 of 2)
Register Overview
User’s Manual 18-26 V2.0, 2007-07
Regs, V2.0
Table 18-13 Address Map of Port 4
Short Name Description Address Access Mode Reset Value
Read Write
Port 4
P4_OUT Port 4 Output Register F000 1000
H
U, SV U, SV 0000 0000
H
P4_OMR Port 4 Output Modification
Register
F000 1004
H
U, SV U, SV,
32
0000 XXXX
H
– Reserved F000 1008
H
-
F000 100C
H
U, SV U, SV –
P4_IOCR0 Port 4 Input/Output
Control Register 0
F000 1010
H
U, SV U, SV 2020 2020
H
P4_IOCR4 Port 4 Input/Output
Control Register 4
F000 1014
H
U, SV U, SV 2020 2020
H
P4_IOCR8 Port 4 Input/Output
Control Register 8
F000 1018
H
U, SV U, SV 2020 2020
H
P4_IOCR12 Port 4 Input/Output
Control Register 12
F000 101C
H
U, SV U, SV 2020 2020
H
– Reserved F000 1020
H
U, SV U, SV –
P4_IN Port 4 Input Register F000 1024
H
U, SV U, SV 0000 XXXX
H
– Reserved F000 1028
H
-
F000 103C
H
U, SV U, SV –
P4_PDR Port 4 Pad Driver Mode
Register
F000 1040
H
U, SV SV, E 0000 0000
H
– Reserved F000 1044
H
-
F000 104C
H
U, SV U, SV –
P4_ESR Port 4 Emergency Stop
Register
F000 1050
H
U, SV SV, E 0000 0000
H
– Reserved F000 1054
H
-
F000 10FC
H
U, SV U, SV –
