Infineon Technologies TC1796 User Manual

TC1796
System Units (Vol. 1 of 2)
Register Overview
User’s Manual 18-25 V2.0, 2007-07
Regs, V2.0
Table 18-12 Address Map of Port 3
Short Name Description Address Access Mode Reset Value
Read Write
Port 3
P3_OUT Port 3 Output Register F000 0F00
H
U, SV U, SV 0000 0000
H
P3_OMR Port 3 Output
Modification Register
F000 0F04
H
U, SV U, SV,
32
0000 XXXX
H
– Reserved F000 0F08
H
-
F000 0F0C
H
U, SV U, SV –
P3_IOCR0 Port 3 Input/Output
Control Register 0
F000 0F10
H
U, SV U, SV 2020 2020
H
P3_IOCR4 Port 3 Input/Output
Control Register 4
F000 0F14
H
U, SV U, SV 2020 2020
H
P3_IOCR8 Port 3 Input/Output
Control Register 8
F000 0F18
H
U, SV U, SV 2020 2020
H
P3_IOCR12 Port 3 Input/Output
Control Register 12
F000 0F1C
H
U, SV U, SV 2020 2020
H
– Reserved F000 0F20
H
U, SV U, SV –
P3_IN Port 3 Input Register F000 0F24
H
U, SV U, SV 0000 XXXX
H
– Reserved F000 0F28
H
-
F000 0F3C
H
U, SV U, SV –
P3_PDR Port 3 Pad Driver Mode
Register
F000 0F40
H
U, SV SV, E 0000 0000
H
– Reserved F000 0F44
H
-
F000 0F4C
H
U, SV U, SV –
P3_ESR Port 3 Emergency Stop
Register
F000 0F50
H
U, SV SV, E 0000 0000
H
– Reserved F000 0F54
H
-
F000 0FFC
H
U, SV U, SV –
