Infineon Technologies TC1796 User Manual

TC1796
System Units (Vol. 1 of 2)
Register Overview
User’s Manual 18-24 V2.0, 2007-07
Regs, V2.0
Table 18-11 Address Map of Port 2
Short Name Description Address Access Mode Reset Value
Read Write
Port 2
P2_OUT Port 2 Output Register F000 0E00
H
U, SV U, SV 0000 0000
H
P2_OMR Port 2 Output
Modification Register
F000 0E04
H
U, SV U, SV,
32
0000 XXXX
H
– Reserved F000 0E08
H
-
F000 0E0C
H
U, SV U, SV –
P2_IOCR0 Port 2 Input/Output
Control Register 0
F000 0E10
H
U, SV U, SV 2020 2020
H
P2_IOCR4 Port 2 Input/Output
Control Register 4
F000 0E14
H
U, SV U, SV 2020 2020
H
P2_IOCR8 Port 2 Input/Output
Control Register 8
F000 0E18
H
U, SV U, SV 2020 2020
H
P2_IOCR12 Port 2 Input/Output
Control Register 12
F000 0E1C
H
U, SV U, SV 2020 2020
H
– Reserved F000 0E20
H
U, SV U, SV –
P2_IN Port 2 Input Register F000 0E24
H
U, SV U, SV 0000 XXXX
H
– Reserved F000 0E28
H
-
F000 0E3C
H
U, SV U, SV –
P2_PDR Port 2 Pad Driver Mode
Register
F000 0E40
H
U, SV SV, E 0000 0000
H
– Reserved F000 0E44
H
-
F000 0E4C
H
U, SV U, SV –
P2_ESR Port 2 Emergency Stop
Register
F000 0E50
H
U, SV SV, E 0000 0000
H
– Reserved F000 0E54
H
-
F000 0EFC
H
U, SV U, SV –
