Infineon Technologies TC1796 User Manual

TC1796
System Units (Vol. 1 of 2)
Register Overview
User’s Manual 18-30 V2.0, 2007-07
Regs, V2.0
Table 18-17 Address Map of Port 8
Short Name Description Address Access Mode Reset Value
Read Write
Port 8
P8_OUT Port 8 Output Register F000 1400
H
U, SV U, SV 0000 0000
H
P8_OMR Port 8 Output Modification
Register
F000 1404
H
U, SV U, SV,
32
0000 00XX
H
– Reserved F000 1408
H
-
F000 140C
H
U, SV U, SV –
P8_IOCR0 Port 8 Input/Output
Control Register 0
F000 1410
H
U, SV U, SV 2020 2020
H
P8_IOCR4 Port 8 Input/Output
Control Register 4
F000 1414
H
U, SV U, SV 2020 2020
H
– Reserved F000 1418
H
-
F000 1420
H
U, SV U, SV –
P8_IN Port 8 Input Register F000 1424
H
U, SV U, SV 0000 00XX
H
– Reserved F000 1428
H
-
F000 143C
H
U, SV U, SV –
P8_PDR Port 8 Pad Driver Mode
Register
F000 1440
H
U, SV SV, E 0000 0000
H
– Reserved F000 1444
H
-
F000 144C
H
U, SV U, SV –
P8_ESR Port 8 Emergency Stop
Register
F000 1450
H
U, SV SV, E 0000 0000
H
– Reserved F000 1454
H
-
F000 14FC
H
U, SV U, SV –
