Infineon Technologies TC1796 User Manual

TC1796
System Units (Vol. 1 of 2)
Register Overview
User’s Manual 18-31 V2.0, 2007-07
Regs, V2.0
Table 18-18 Address Map of Port 9
Short Name Description Address Access Mode Reset Value
Read Write
Port 9
P9_OUT Port 9 Output Register F000 1500
H
U, SV U, SV 0000 0000
H
P9_OMR Port 9 Output Modification
Register
F000 1504
H
U, SV U,
SV,
32
0000 0XXX
H
– Reserved F000 1508
H
-
F000 150C
H
U, SV U, SV –
P9_IOCR0 Port 9 Input/Output
Control Register 0
F000 1510
H
U, SV U, SV 2020 2020
H
P9_IOCR4 Port 9 Input/Output
Control Register 4
F000 1514
H
U, SV U, SV 2020 2020
H
P9_IOCR8 Port 9 Input/Output
Control Register 8
F000 1518
H
U, SV U, SV 0000 0020
H
– Reserved F000 151C
H
-
F000 1520
H
U, SV U, SV –
P9_IN Port 9 Input Register F000 1524
H
U, SV U, SV 0000 0XXX
H
– Reserved F000 1528
H
-
F000 153C
H
U, SV U, SV –
P9_PDR Port 9 Pad Driver Mode
Register
F000 1540
H
U, SV SV, E 0000 0000
H
– Reserved F000 1544
H
-
F000 154C
H
U, SV U, SV –
P9_ESR Port 9 Emergency Stop
Register
F000 1550
H
U, SV SV, E 0000 0000
H
– Reserved F000 1554
H
-
F000 15FC
H
U, SV U, SV –
