GPTA0_
LTCCTRn
GPTA0 Local Timer Cell
Control Register n
(n = 00-63)
F000 1A00
H
+ n × 08
H
+ 00
H
U, SV U, SV 0000 0000
H
GPTA0_
LTCXRn
GPTA0 Local Timer Cell
X Register n
(n = 00-63)
F000 1A00
H
+ n × 08
H
+ 04
H
U, SV U, SV 0000 0000
H
GPTA0_
EDCTR
GPTA Clock Enable/
Disable Control Register
F000 1C00
H
U, SV U, SV 0000 0000
H
– Reserved F000 1C04
H
-
F000 1EFC
H
nBE nBE –
GPTA0_
MMXCTR00
GPTA-to-MSC
Multiplexer Control
Register 00
F000 1F00
H
U, SV U, SV 0000 0000
H
GPTA0_
MMXCTR01
GPTA-to-MSC
Multiplexer Control
Register 01
F000 1F04
H
U, SV U, SV 0000 0000
H
GPTA0_
MMXCTR10
GPTA-to-MSC
Multiplexer Control
Register 10
F000 1F08
H
U, SV U, SV 0000 0000
H
GPTA0_
MMXCTR11
GPTA-to-MSC
Multiplexer Control
Register 11
F000 1F0C
H
U, SV U, SV 0000 0000
H
– Reserved F000 1F10
H
-
F000 1F64
H
nBE nBE –
GPTA0_
SRC37
GPTA0 Service Request
Control Register 37
F000 1F68
H
U, SV U, SV 0000 0000
H
GPTA0_
SRC36
GPTA0 Service Request
Control Register 36
F000 1F6C
H
U, SV U, SV 0000 0000
H
GPTA0_
SRC35
GPTA0 Service Request
Control Register 35
F000 1F70
H
U, SV U, SV 0000 0000
H
GPTA0_
SRC34
GPTA0 Service Request
Control Register 34
F000 1F74
H
U, SV U, SV 0000 0000
H
GPTA0_
SRC33
GPTA0 Service Request
Control Register 33
F000 1F78
H
U, SV U, SV 0000 0000
H
