TC1796

System Units (Vol. 1 of 2)

Register Overview

User’s Manual 18-39 V2.0, 2007-07

Regs, V2.0

GPTA0_

SRC32

GPTA0 Service Request

Control Register 32

F000 1F7C

H

U, SV U, SV 0000 0000

H

GPTA0_

SRC31

GPTA0 Service Request

Control Register 31

F000 1F80

H

U, SV U, SV 0000 0000

H

GPTA0_

SRC30

GPTA0 Service Request

Control Register 30

F000 1F84

H

U, SV U, SV 0000 0000

H

GPTA0_

SRC29

GPTA0 Service Request

Control Register 29

F000 1F88

H

U, SV U, SV 0000 0000

H

GPTA0_

SRC28

GPTA0 Service Request

Control Register 28

F000 1F8C

H

U, SV U, SV 0000 0000

H

GPTA0_

SRC27

GPTA0 Service Request

Control Register 27

F000 1F90

H

U, SV U, SV 0000 0000

H

GPTA0_

SRC26

GPTA0 Service Request

Control Register 26

F000 1F94

H

U, SV U, SV 0000 0000

H

GPTA0_

SRC25

GPTA0 Service Request

Control Register 25

F000 1F98

H

U, SV U, SV 0000 0000

H

GPTA0_

SRC24

GPTA0 Service Request

Control Register 24

F000 1F9C

H

U, SV U, SV 0000 0000

H

GPTA0_

SRC23

GPTA0 Service Request

Control Register 23

F000 1FA0

H

U, SV U, SV 0000 0000

H

GPTA0_

SRC22

GPTA0 Service Request

Control Register 22

F000 1FA4

H

U, SV U, SV 0000 0000

H

GPTA0_

SRC21

GPTA0 Service Request

Control Register 21

F000 1FA8

H

U, SV U, SV 0000 0000

H

GPTA0_

SRC20

GPTA0 Service Request

Control Register 20

F000 1FAC

H

U, SV U, SV 0000 0000

H

GPTA0_

SRC19

GPTA0 Service Request

Control Register 19

F000 1FB0

H

U, SV U, SV 0000 0000

H

GPTA0_

SRC18

GPTA0 Service Request

Control Register 18

F000 1FB4

H

U, SV U, SV 0000 0000

H

GPTA0_

SRC17

GPTA0 Service Request

Control Register 17

F000 1FB8

H

U, SV U, SV 0000 0000

H

Table 18-20 Address Map of GPTA0 (cont’d)

Short

Name

Description Address Access Mode Reset Value

Read Write
