Infineon Technologies TC1796 User Manual

TC1796
System Units (Vol. 1 of 2)
Register Overview
User’s Manual 18-40 V2.0, 2007-07
Regs, V2.0
GPTA0_
SRC16
GPTA0 Service Request
Control Register 16
F000 1FBC
H
U, SV U, SV 0000 0000
H
GPTA0_
SRC15
GPTA0 Service Request
Control Register 15
F000 1FC0
H
U, SV U, SV 0000 0000
H
GPTA0_
SRC14
GPTA0 Service Request
Control Register 14
F000 1FC4
H
U, SV U, SV 0000 0000
H
GPTA0_
SRC13
GPTA0 Service Request
Control Register 13
F000 1FC8
H
U, SV U, SV 0000 0000
H
GPTA0_
SRC12
GPTA0 Service Request
Control Register 12
F000 1FCC
H
U, SV U, SV 0000 0000
H
GPTA0_
SRC11
GPTA0 Service Request
Control Register 11
F000 1FD0
H
U, SV U, SV 0000 0000
H
GPTA0_
SRC10
GPTA0 Service Request
Control Register 10
F000 1FD4
H
U, SV U, SV 0000 0000
H
GPTA0_
SRC09
GPTA0 Service Request
Control Register 09
F000 1FD8
H
U, SV U, SV 0000 0000
H
GPTA0_
SRC08
GPTA0 Service Request
Control Register 08
F000 1FDC
H
U, SV U, SV 0000 0000
H
GPTA0_
SRC07
GPTA0 Service Request
Control Register 07
F000 1FE0
H
U, SV U, SV 0000 0000
H
GPTA0_
SRC06
GPTA0 Service Request
Control Register 06
F000 1FE4
H
U, SV U, SV 0000 0000
H
GPTA0_
SRC05
GPTA0 Service Request
Control Register 05
F000 1FE8
H
U, SV U, SV 0000 0000
H
GPTA0_
SRC04
GPTA0 Service Request
Control Register 04
F000 1FEC
H
U, SV U, SV 0000 0000
H
GPTA0_
SRC03
GPTA0 Service Request
Control Register 03
F000 1FF0
H
U, SV U, SV 0000 0000
H
GPTA0_
SRC02
GPTA0 Service Request
Control Register 02
F000 1FF4
H
U, SV U, SV 0000 0000
H
Table 18-20 Address Map of GPTA0 (cont’d)
Short
Name
Description Address Access Mode Reset Value
Read Write
