TC1796
System Units (Vol. 1 of 2)
Register Overview
User’s Manual 18-87 V2.0, 2007-07
Regs, V2.0
Table 18-29 Address Map of ADC0/ADC1
Short Name Description Address Access Mode Reset Value
Read Write
Analog-to-Digital Converter 0 (ADC0)
ADC0_CLC ADC Clock Control
Register
F010 0400
HF
U, SV SV, E 0000 0003
H
– Reserved F010 0404
H
BE BE –
ADC0_ID ADC Module Identification
Register
F010 0408
H
U, SV BE 0030 C0XX
H
ADC0_FDR ADC Fractional Divider
Register
F010 040C
H
U, SV SV, E 0000 0000
H
ADC0_
CHCON0
ADC0 Channel Control
Register 0
F010 0410
H
U, SV U, SV 0000 0000
H
ADC0_
CHCON1
ADC0 Channel Control
Register 1
F010 0414
H
U, SV U, SV 0000 0000
H
ADC0_
CHCON2
ADC0 Channel Control
Register 2
F010 0418
H
U, SV U, SV 0000 0000
H
ADC0_
CHCON3
ADC0 Channel Control
Register 3
F010 041C
H
U, SV U, SV 0000 0000
H
ADC0_
CHCON4
ADC0 Channel Control
Register 4
F010 0420
H
U, SV U, SV 0000 0000
H
ADC0_
CHCON5
ADC0 Channel Control
Register 5
F010 0424
H
U, SV U, SV 0000 0000
H
ADC0_
CHCON6
ADC0 Channel Control
Register 6
F010 0428
H
U, SV U, SV 0000 0000
H
ADC0_
CHCON7
ADC0 Channel Control
Register 7
F010 042C
H
U, SV U, SV 0000 0000
H
ADC0_
CHCON8
ADC0 Channel Control
Register 8
F010 0430
H
U, SV U, SV 0000 0000
H
ADC0_
CHCON9
ADC0 Channel Control
Register 9
F010 0434
H
U, SV U, SV 0000 0000
H
ADC0_
CHCON10
ADC0 Channel Control
Register 10
F010 0438
H
U, SV U, SV 0000 0000
H
ADC0_
CHCON11
ADC0 Channel Control
Register 11
F010 043C
H
U, SV U, SV 0000 0000
H
