TC1796
System Units (Vol. 1 of 2)
Register Overview
User’s Manual 18-103 V2.0, 2007-07
Regs, V2.0
Table 18-31 Address Map of MCHK
Short Name Description Address Access Mode Reset Value
Read Write
Memory Checker (MCHK)
1)
– Reserved F010 C200
H
-
F010 C204
H
BE BE –
MCHK_ID Memory Checker Module
Identification Register
F010 C208
H
U, SV BE 001B C0XX
H
– Reserved F010 C20C
H
BE BE –
MCHK_IR Memory Checker Input
Register
F010 C210
H
U, SV U, SV 0000 0000
H
MCHK_RR Memory Checker Result
Register
F010 C214
H
U, SV U, SV 0000 0000
H
– Reserved F010 C218
H
-
F010 C21C
H
BE BE –
MCHK_WR Memory Checker Write
Register
F010 C220
H
U, SV U, SV 0000 0000
H
– Reserved F010 C224
H
-
F010 C2FC
H
BE BE –
1) The reset values of the memory checker registers can be modified into initial values after Boot ROM exit. See
Table 4-4 on Page 4-19 for more details.
