TC1796

System Units (Vol. 1 of 2)

User’s Manual 18-104 V2.0, 2007-07

Regs, V2.0

Table 18-32 Address Map of CPS

Short Name Description Address Access Mode Reset Value

Read Write

CPU Slave Interface Registers (CPS)

– Reserved F7E0 FF00

F7E0 FF04

BE BE –

CPS_ID CPS Module

Identification Register

F7E0 FF08

U, SV U,

SV,

0015 C0XX

– Reserved F7E0 FF0C

FFFE FFB8

BE BE –

CPU_

SBSRC0

CPU Software Break

Service Request Control

F7E0 FFBC

U, SV SV 0000 0000

– Reserved F7E0 FFC0

F7E0 FFEC

BE BE –

CPU_SRC3 CPU Service Request

Control Register 3

F7E0 FFF0

U, SV SV 0000 0000

CPU_SRC2 CPU Service Request

Control Register 2

F7E0 FFF4

U, SV SV 0000 0000

CPU_SRC1 CPU Service Request

Control Register 1

F7E0 FFF8

U, SV SV 0000 0000

CPU_SRC0 CPU Service Request

Control Register 0

F7E0 FFFC

U, SV SV 0000 0000
