Infineon Technologies TC1796 User Manual

TC1796
System Units (Vol. 1 of 2)
Register Overview
User’s Manual 18-117 V2.0, 2007-07
Regs, V2.0
Table 18-36 Address Map of Flash
Short Name Description Address Access Mode Reset Value
Read Write
Flash Register
– Reserved F800 1000
H
-
F800 2004
H
BE BE –
FLASH_ID Flash Module
Identification Register
F800 2008
H
U, SV BE 0031 C0XX
H
– Reserved F800 200C
H
BE BE –
FLASH_
FSR
Flash Status Register F800 2010
H
U, SV BE 0XXX X0X0
H
FLASH_
FCON
Flash Configuration
Register
F800 2014
H
U, SV SV, E 000X 0636
H
FLASH_
MARP
Flash Margin Control
Register PFlash
F800 2018
H
U, SV SV, E 0000 8000
H
FLASH_
MARD
Flash Margin Control
Register DFlash
F800 201C
H
U, SV U, SV 0000 8000
H
FLASH_
PROCON0
Flash Protection Config.
Register User 0
F800 2020
H
U, SV BE 0000 XXXX
H
FLASH_
PROCON1
Flash Protection Config.
Register User 1
F800 2024
H
U, SV BE 0000 XXXX
H
FLASH_
PROCON2
Flash Protection Config.
Register User 2
F800 2028
H
U, SV BE 0000 XXXX
H
– Reserved F800 202C
H
-
F800 23FC
H
BE BE –
