TC1796

System Units (Vol. 1 of 2)

User’s Manual 18-121 V2.0, 2007-07

Regs, V2.0

DMU_

RABR14

DMU Redirected Address

Base Register 14

F801 01C8

U, SV SV 0000 0000

DMU_

OTAR14

DMU Overlay Target

Address Register 14

F801 01CC

U, SV SV 0000 0000

DMU_

OMASK14

DMU Overlay Mask

F801 01D0

U, SV SV 0FFF FE00

DMU_

RABR15

DMU Redirected Address

Base Register 15

F801 01D4

U, SV SV 0000 0000

DMU_

OTAR15

DMU Overlay Target

Address Register 15

F801 01D8

U, SV SV 0000 0000

DMU_

OMASK15

DMU Overlay Mask

F801 01DC

U, SV SV 0FFF FE00

DMU_

SBRCTR

DMU Stand-by SRAM

Control Register

F801 01E0

U, SV SV 0000 0000

– Reserved F801 01E4

F801 01FC

BE BE –

1) Do not read from or write to these address locations. Otherwise unpredictable results may occur.

Table 18-37 Address Map of DMU (cont’d)

Short Name Description Address Access Mode Reset Value

Read Write
