Infineon Technologies TC1796 User Manual

TC1796
System Units (Vol. 1 of 2)
Register Overview
User’s Manual 18-124 V2.0, 2007-07
Regs, V2.0
Table 18-40 Address Map of PMI
Short Name Description Address Access Mode Reset Value
Read Write
PMI Registers
– Reserved F87F FD00
H
-
F87F FD04
H
BE BE –
PMI_ID PMI Module
Identification Register
F87F FD08
H
U, SV,
32
U,
SV,
NC,
32
000B C0XX
H
– Reserved F87F FD0C
H
BE BE –
PMI_CON0 PMI Control Register 0 F87F FD10
H
U, SV,
32
SV,
E, 32
0000 0002
H
PMI_CON1 PMI Control Register 1 F87F FD14
H
U, SV,
32
SV,
32
0000 0000
H
PMI_CON2 PMI Control Register 2 F87F FD18
H
U, SV,
32
SV,
NC,
32
0000 0073
H
– Reserved F87F FD1C
H
-
F87F FDFC
H
BE BE –
