TC1796
Peripheral Units (Vol. 2 of 2)
Micro Second Channel (MSC)
User’s Manual 21-10 V2.0, 2007-07
MSC, V2.0
Table 21-2 Data Frame Selection Bit Parameters
DSC.ENSELL Selection Bit DSC.ENSELH Selection Bit
0 No selection bit inserted
at the beginning of the
SRL active phase
0 No selection bit inserted
at the beginning of the
SRH active phase
1 A low-level selection bit
with is inserted at the
beginning of the SRL
active phase
1 A low-level selection bit
is inserted at the
beginning of the SRH
active phase
Table 21-3 Data Frame SRL/SRH Length Parameters
DSC.NDBL SRL Bits Transmitted
in SRL Active Phase
DSC.NDBH SRH Bits Transmitted
in SRH Active Phase
00000
B
No SRL bit transmitted 00000
B
No SRH bit transmitted
00001
B
SRL[0] 00001
B
SRHL[0]
00010
B
SRL[1:0] 00010
B
SRH[1:0]
00011
B
SRL[2:0] 00011
B
SRH[2:0]
…… ……
01111
B
SRL[14:0] 01111
B
SRH[14:0]
10000
B
SRL[15:0] 10000
B
SRH[15:0]
Other bit
combinations
Reserved; do not use
these bit combinations.
Other bit
combinations
Reserved; do not use
these bit combinations.
Table 21-4 Data Frame Passive Phase Length
DSC.PPD Passive Phase Length
00000
B
2 × t
FCL
00001
B
2 × t
FCL
00010
B
2 × t
FCL
00011
B
3 × t
FCL
……
01110
B
30 × t
FCL
01111
B
31 × t
FCL
