TC1796

Peripheral Units (Vol. 2 of 2)

Micro Second Channel (MSC)

User’s Manual 21-45 V2.0, 2007-07

MSC, V2.0

DC [22:16] rh Downstream Counter

This bit field indicates the number of downstream shift

clock periods that have been elapsed since the start of

the current frame.

No shift clock elapsed (after counter reset).

1 shift clock elapsed.

…

127 shift clocks elapsed.

The DC is reset at the end of a downstream frame.

DFA 24 rh Data Frame Active

This bit indicates if a data frame is currently sent out.

No data frame is currently sent out.

A data frame is currently sent out.

CFA 25 rh Command Frame Active

This bit indicates if a command frame is currently sent

out.

No command frame is currently sent out.

A command frame is currently sent out.

0 [7:4],

[15:12],

23,

[31:26]

r Reserved

Read as 0; should be written with 0.

Field Bits Type Description
