Micro Second Channel (MSC)
User’s Manual 21-71 V2.0, 2007-07
MSC, V2.0
Input/Output Control Registers
P5_IOCR4
Port 5 Input/Output Control Register 4 (14
H
) Reset Value: 2020 2020
H
31 28 23 20 15 12 7 4 0
PC7 0PC60PC50PC40
rw rrwrrwrrwr
Field Bits Type Description
PC4,
PC5,
PC6,
PC7
[7:4],
[15:12],
[23:20],
[31:28]
rw Port Input/Output Control for Port 5.[7:4]
1)
Port input/output control for P5.4/EN00
Port input/output control for P5.5/SDI0
Port input/output control for P5.6/EN10
Port input/output control for P5.7/SDI1
1) Coding of bit field see Table 21-11. Shaded bits and bit fields are “don’t care” for MSC I/O port control.
P9_IOCR0
Port 9 Input/Output Control Register 0 (10
H
) Reset Value: 2020 2020
H
31 28 23 20 15 12 7 4 0
PC3 0PC20PC10PC00
rw rrwrrwrrwr
Field Bits Type Description
PC0,
PC1,
PC2,
PC3
[7:4],
[15:12],
[23:20],
[31:28]
rw Port Input/Output Control for Port 9 Pins 1-3
1)
Port input/output control for P9.0/EN12
Port input/output control for P9.1/EN11
Port input/output control for P9.2/SOP1B
Port input/output control for P9.3/FCLP1B
1) Coding of bit field see Table 21-11. Shaded bits and bit fields are “don’t care” for MSC I/O port control.
