TC1796

Peripheral Units (Vol. 2 of 2)

Controller Area Network (MultiCAN) Controller

User’s Manual 22-112 V2.0, 2007-07

MultiCAN, V2.0

Message Object n Data Register Low MODATAL contains the lowest four data bytes of

message object n. Unused data bytes are set to zero upon reception and ignored for

transmission.

MODATALn (n = 0-127)

Message Object n Data Register Low

(0610

+n*20

) Reset Value: 0000 0000

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

DB3 DB2

rwh rwh

1514131211109876543210

DB1 DB0

rwh rwh

Field Bits Type Description

DB0 [7:0] rwh Data Byte 0 of Message Object n

DB1 [15:8] rwh Data Byte 1 of Message Object n

DB2 [23:16] rwh Data Byte 2 of Message Object n

DB3 [31:24] rwh Data Byte 3 of Message Object n
