TC1796

Peripheral Units (Vol. 2 of 2)

Controller Area Network (MultiCAN) Controller

User’s Manual 22-113 V2.0, 2007-07

MultiCAN, V2.0

Message Object n Data Register High MODATAH contains the highest four data bytes

of message object n. Unused data bytes are set to zero upon reception and ignored for

transmission.

MODATAHn (n = 0-127)

Message Object n Data Register High

(0614

+n*20

) Reset Value: 0000 0000

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

DB7 DB6

rwh rwh

1514131211109876543210

DB5 DB4

rwh rwh

Field Bits Type Description

DB4 [7:0] rwh Data Byte 4 of Message Object n

DB5 [15:8] rwh Data Byte 5 of Message Object n

DB6 [23:16] rwh Data Byte 6 of Message Object n

DB7 [31:24] rwh Data Byte 7 of Message Object n
