MPE [7:4] rwh Maximum Parity Errors
This bit field determines the maximum number of
transmitter parity error conditions that can be still
detected until a transmitter parity error event is
generated (see Page 23-42). With each condition
detected, MPE is decremented down to 0.
0000
B
A parity error event is generated if a transmitter
parity error condition is detected.
0001
B
A parity error event is generated if a transmitter
parity error condition is detected.
0010
B
A parity error event is generated if 2 transmitter
parity error conditions are detected.
0011
B
A parity error event is generated if 3 transmitter
parity error conditions are detected.
…
B
…
1110
B
A parity error event is generated if 14 transmitter
parity error conditions are detected.
1111
B
A parity error event is generated if 15 transmitter
parity error conditions are detected.
MNAE [9:8] rwh Maximum Non Acknowledge Errors
This bit field determines the maximum number of
consecutive Non-Acknowledge error conditions that
can be still detected in the transmitter until a time-out
event is generated. MNAE is decremented down to 0 at
each Non-Acknowledge error condition. When
MNAE = 0 or becoming 0, a time-out event is
generated. MNAE is automatically set to 11
B
after a
successful frame transmission (see Page 23-45).
00
B
A time-out event is generated if 1 non-ack
condition is detected.
01
B
A time-out event is generated if 1 non-ack
condition is detected.
10
B
A time-out event is generated if 2 consecutive
non-ack conditions are detected.
11
B
A time-out event is generated if 3 consecutive
non-ack conditions are detected.
Field Bits Type Description
