TC1796
Peripheral Units (Vol. 2 of 2)
Micro Link Interface (MLI)
User’s Manual 23-102 V2.0, 2007-07
MLI, V2.0
The write-only Transmitter Pipe x Base Address Register TPxBAR represents the 28-bit
pipe x Remote Window base address and the Remote Window size that is transmitted
to the receiving controller via a Copy Base Address Frame.
TPxBAR (x = 0-3)
Transmitter Pipe x Base Address Register
(54
H
+4
H
*x) Reset Value: 0000 0000
H
31 43 0
ADDR BS
ww
Field Bits Type Description
BS [3:0] w Buffer Size
This bit field determines the coded buffer size of the
pipe x Remote Window in the receiving controller. When
writing TPxBAR, BS is copied into bit field
TPxSTATR.BS.
0000
B
1-bit offset address of Remote Window
0001
B
2-bit offset address of Remote Window
0010
B
3-bit offset address of Remote Window
…
B
…
1110
B
15-bit offset address of Remote Window
1111
B
16-bit offset address of Remote Window
ADDR [31:4] w Address
This bit field determines the most significant 28 bits of
the pipe x Remote Window base address. When writing
TPxBAR, ADDR is copied into bit field
TCBAR.ADDR[31:4].
