Micro Link Interface (MLI)
User’s Manual 23-131 V2.0, 2007-07
MLI, V2.0
MLI0 P1.8 / RCLK0A P1_IOCR8.PC8 = 0XXX
B
1)
MLI0_OICR.RCE = 1
MLI0_OICR.RCP = X
2)
MLI0_OICR.RCS = 00
B
Input
P1.9 / RREADY0A P1_IOCR8.PC9 = 1X01
B
1)
MLI0_OICR.RRS = 00
B
MLI0_OICR.RRPA = X
2)
Output
P1.10 / RVALID0A P1_IOCR8.PC10 = 0XXX
B
1)
MLI0_OICR.RVE = 1
MLI0_OICR.RVP = X
2)
MLI0_OICR.RVS = 00
B
Input
P1.11 / RDATA0A P1_IOCR8.PC11 = 0XXX
B
1)
MLI1_OICR.RDP = X
2)
MLI1_OICR.RDS = 00
B
Input
P1.13 / RCLK0B P1_IOCR12.PC13 = 0XXX
B
1)
MLI0_OICR.RCE = 1
MLI0_OICR.RCP = X
2)
MLI0_OICR.RCS = 01
B
Input
P1.14 / RVALID0B P1_IOCR12.PC14 = 0XXX
B
1)
MLI0_OICR.RVE = 1
MLI0_OICR.RVP = X
2)
MLI0_OICR.RVS = 01
B
Input
P1.15 / RDATA0B P1_IOCR12.PC15 = 0XXX
B
1)
MLI1_OICR.RDP = X
2)
MLI1_OICR.RDS = 01
B
Input
P5.4 / RREADY0B P5_IOCR4.PC4 = 1X10
B
1)
MLI0_OICR.RRS = 01
B
MLI0_OICR.RRPB = X
2)
Output
P5.6 / TVALID0B P5_IOCR4.PC6 = 1X10
B
1)
MLI0_OICR.TVEB = 1
MLI0_OICR.TVPB = X
2)
Output
Table 23-11 MLI0 and MLI1 I/O Line Selection and Setup (cont’d)
Module Port Lines Input/Output Control
Register Bits
I/O
