TC1796

Peripheral Units (Vol. 2 of 2)

General Purpose Timer Array (GPTA)

User’s Manual 24-120 V2.0, 2007-07

GPTA, V2.0

Global variables

Name k = [0 to 5] for FPC Short

Name

(*)FPC

Size

(bits)

Function

FPCk.Mode *MODk 3 Selects one of these modes:

DELAYED_FILTER_BOTH

IMMEDIATE_FILTER_BOTH

IMMEDIATE_FILTER_RISING

IMMEDIATE_FILTER_FALLING

MIXED_FILTER_RISING_DELAYED

MIXED_FILTER_RISING_IMMEDIATE

PRESCALER_RISING

PRESCALER_FALLING

FPCk.Input_Source *IPSk 3 Selects input signal

FPCk.Clock_Source *CLKk 2 Selects FPC clock

FPCk.Rising_Edge_Glitch *REGk 1 Bit is set when rising edge glitch occurs

during filtering

FPCk.Falling_Edge_Glitch *FEGk 1 Bit is set when falling edge glitch occurs

during filtering

FPCk.Timer *TIMk 16 Timer value

FPCk.Reset_Timer *RTGk 1 Reset timer on glitch in Delayed Filter

Mode

FPCk.Compare_Value *CMPk 16 Compare value
