TC1796

Peripheral Units (Vol. 2 of 2)

General Purpose Timer Array (GPTA)

User’s Manual 24-126 V2.0, 2007-07

GPTA, V2.0

Check_Input()

if (DCMk.Signal_Input.Transition) then

if (DCMk.Signal_Input.Level) then //rising edge

trig(DCMk.Service_Request_Rising)

if (DCMk.Capture_On_Rising_Edge) then

DCMk.Capture_Value = DCMk.Timer

else

if (DCMk.Capcom_Opposite) then

DCMk.Capcom_Value = DCMk.Timer

endif

if (DCMk.Clear_On_Rising_Edge) then

DCMk.Timer = 0

else DCMk.Timer ++

endif

if (DCMk.Clock_On_Rising_Edge) then

Generate pulse on DCMk.Signal_Output

endif

else //falling edge

trig(DCMk.Service_Request_Falling)

if (!DCMk.Capture_On_Rising_Edge) then

DCMk.Capture_Value = DCMk.Timer

else

if (DCMk.Capcom_Opposite) then

DCMk.Capcom_Value = DCMk.Timer

endif

if (DCMk.Clear_On_Falling_Edge) then

DCMk.Timer = 0

else DCMk.Timer ++

endif

if (DCMk.Clock_On_Falling_Edge) then

Generate pulse on DCMk.Signal_Output

endif

else DCMk.Timer ++

endif
